4KW 5.5HP Twin Cylinder Air Compressor Pump Head Double Stage V-Type Pump Replacement 800RPM 175PSI 8~11CFM

Specifications Air delivery: 8~11CFMRated pressure: 175 PSI (1.16MPa)Driving power: 4KW (5.5HP) Pump speed: 800RPMCylinder diameter: 3.54" (90mm)Distance of screw hole: 26cm*14cm (10.2"*5.5")Rated exhaust volume: 0.6L/MinNote: If the motor speed is 2880rpm, the diameter of the motor wheel is 10 cm. If the motor speed is 1440rpm, the motor wheel is 20 cmFeaturesHigh efficiency, high precision, universal, low energy consumption.High quality material, not easy to damage.Strict balance support and correction to ensure the smooth operation of the main engine.Special valve steel is used for hair piece, which has good strength and toughness at high temperature.Faster inflation and low noise.Strong cooling blade, good cooling performance.Installation NotesWhen placing the pump head, the motor pulley and the belt pulley must be in the same straight line. The more aligned, the less vibration.Tighten the screws (including the base and pulley screws).After the screws are installed, the belt shall be tightened. If the belt is loose, please move the motor. After the screws are tightened, reinstall the belt.The new machine must be filled with engine oil before starting, and the engine oil shall be added to the center of the red point of the oil mirror.The rotation direction of the pump head is clockwise. If it reverses, please adjust it in time.Change the oil for the first half month, the second one and a half months, and the next two to three months.Replace the air filter regularly. Under normal conditions, it must be replaced in two to three months, and in case of poor environment, it must be replaced in one month.The operation of the machine will produce high temperature, be careful not to burn!Package Included1* Air Compressor Pump head

• 💎【Important Parameters】Driving power: 4KW (5.5HP) ;Pump speed: 800RPM; Rated pressure: 175 PSI (1.16MPa); Air delivery: 8~11CFM; Cylinder diameter: 3.54" (90mm); Rated exhaust volume: 0.6L/Min; Distance of screw hole: 26cm*14cm (10.2"*5.5"); Cylinder diameter: 3.54" (90mm)
• 💎【Excellent Cooling Performance】The cooling blade is strong and has good cooling performance. Widely used in factories, home improvement, auto repair, painting and other industries
• 💎【Smooth Running】The hair piece is made of special valve steel, which has good strength and toughness under high temperature. At the same time, strict balance support and correction to ensure the smooth operation of the host and improve efficiency
• 💎【High Efficiency】This twin-cylinder air compressor head is fast filling and low noise. In addition, it also has the advantages of high efficiency, high precision, low energy consumption and high versatility
• 💎【Durable and Sturdy】The head of this twin-cylinder air compressor is made of high-quality material, which is durable and not easy to be damaged. You can save money by using it for a long time without replacing it with a new one
